Newcon Optik AN 7x50MC Binocular
The AN 7x50MC incorporates BAK-4 Porro prisms and multi-coated lenses, delivering impressive light transmission and resolution for brilliantly clear vision. Non-slip UV-resistant rubber armouring makes this unit comfortable to operate even in cold weather.
The AN 7x50MC is waterproof and shockproof, features a military reticle and compass and adheres to the latest military standards while remaining light and compact.
Features:
| Crystal clear optics |
| M22 Reticle |
| Rugged design |
| Extremely compact |
| Built-in illuminated compass |
Specifications:
- Magnification (x) - 7
- Objective lens diameter (mm) - 50
- Focus range (m) - 5 – ∞
- Exit pupil (mm) - 7
- Eye relief (mm) - 23
- Field of view – Angular (°) - 7.2
- Apparent field of view (°) - 50.4
- Field of view @ 1,000y (feet) - 379
- Field of view @ 1,000m (metres) - 126
- Diopter adjustment range - ±5
- Twilight factor - 19
- Relative brightness - 49
- Transmission (%) - 95
- Lens & prism coating - FMC
- Prism type - Porro
- Prism glass material - BAK-4
- Reticle type - M22
- Interpupillary distance (mm) - 56-74
- Weight (g) - 1,046
- Dimensions (mm) - 152x190x83
- Illuminated compass - Yes
- Tripod mountable - Yes
- Battery type - LR44
- Operating temperature range (°C) - 30 to 60
- Storage temperature range (°C) - 45 to 75
- Nitrogen purged - Yes
- Waterproofing - MIL-STD-810G
